Linq to sql comes with a really nice GUI to create those .dbml-files (which then will be used to create code). This works well for SQL Server Databases. Anyway - Linq to sql may also be used to access Sql Compact Edition but you can't use the GUI to drag-drop tables from an SQL-CE-Database onto the dbml-Editor. There are a lot of articles on the web which use SqlMetal to create that dbml-file which then can be used inside Visual Studios GUI. Also there seemed to be not only few people that wanted SqlMetal to skip some tables - this would be very useful when you often change something in your DB-
Schema but not want to drop every unused table every time again in the GUI or maybe if you want to rename some columns afterwards... So - recently I was in this situation and it was absolutely clear that there will be more of that work... so what I was looking for was a way to script that dbml-generation with support to exclude and rename tables and more (since we often deal with prefixes at our tables which I dont want inside my LinqClasses). After some research I figured out a way that works pretty nice for me. I wont go too much into details here because its too much..
First of all I used ildasm to disassemble SqlMetal into IL-Code via dump. Then I replaced most of the private words with public and added public here and there later when needed. Then I re-assembled that code using ilasm with the /DLL option. Finally I had a nice DLL where all that stuff I needed was no longer internal - it was all public - so I went on and created an own console-project which uses the SqlMetal.dll (the filename really MUST be SqlMetal.dll). I took the important parts of the old main method using .NET-Reflector and finally I had the pieces seperated where the the dbml-structure was extracted from an .sdf-file and where this structure was used to generate the .dbml-file. Nice. This structure is very simple to modify and the changes are copied to the dbml without any problems except if you change a name of a type and not change the type-reference in the association objects. Finally I did not want to write special code into this project everytime I have to deal with a new .sdf-file I decided to use the luainterface project to embed the lua-scripting language (very often used in games) to use lua-code for callbacks such as table exclusion, table and relation renaming, column renaming and whatever comes away... all I now have to do when it comes to dbml creation is to start my console
tool with a little lua-script as an argument and this (might) register some hooks where I may react to some columns by returning a different name. quite simple isn't it?? Oh well - some might be wondering how this stuff works - since sqlMetal is strong named... well since I will use this tool only in development I simply skipped the Strongname verification on my machine for that assembly by reflecting its strong name and using sn.exe to add the skipping rule like that
sn.exe -Vr *,<strongname-key>
I don't know if this is possible with earlier versions of sn.exe - I am using VS2008 SP1 by now.
So in the end I named the prog SqlCerium - since it is SqlMetal specialized for SQL CE and Ce is the chemical symbol for Cerium which is also a metal
